One Shot Depositor

One shot chocolate depositor for solid of soft centre chocolates.

Built in China & UK

Interested?

Call: +44 (0) 1253 882 961
E-Mail: sales@loynds.co.uk
for more information.

Get Quote

One Shot Depositor Features:

  • Separation design between depositing system and piston system
  • Non-leakage design of piston system
  • Continuous depositing with once positioning
Pistons 48 sets
Quantity of one shot products per cycle 24 pcs
Depositing mode 3D move depositing
Servo motors 5 sets
Moving axis X, Y, Z
Flowing axis A, B
Operating system One shot system
Can be upgraded to Decoration system
Depositing accuracy ≤±0.1g
Depositing speed 360-720pcs/min
Filling rate ≤85% (2D/3D chocolate)
Power 6.93KW
Compressed air 120L/h
Dimension 1.50m x 1.25m x 1.90m
