The Logo Candy Disc Cutting Machine, including models DC01 (800mm wide) and DC02 (1000mm wide), is a specialized piece of machinery designed for precision cutting of a candy rope into uniform disc shapes or balls. Ideal for manufacturing candy with intricate designs inside the rope such as logos, fruits, faces, or lettering.

These machines ensure that the central designs remain clearly visible and intact in each candy disc. The cutting process not only standardizes the size of each candy disc but also precisely rounds the edges, enhancing the product’s aesthetic appeal.

The machine is popular with manufacturers of promotional candy who are putting customers designs into candy.

Key Features of the Candy Disc Cutting Machine

1. Precision Cutting Mechanism: Ensures uniformity in size and shape of candy discs, preserving the integrity of central designs.
2. Variable Speed Control: Offers flexibility to adjust the cutting speed according to production requirements.
3. Customizable Components: Equipped with interchangeable rollers and cutters, allowing customization for different diameters and lengths of cut discs.
4. Integration with Production Line: Optimally used in tandem with a batch roller and rope sizer, facilitating seamless continuous production.
5. Additional Equipment Option: Can be supplied with a single-tier shaking bed cooler for enhanced cooling efficiency.
6. Ball or Disc Cutting: The machine can manufacture both discs and balls by simply swapping in and out the cutters

Machine Components

• Infeed Rollers (Two Sets): Facilitate smooth feeding of candy rope into the cutting mechanism.
• Long Rope Cutter: Precisely sizes the candy rope before disc cutting.
• Rope Transfer System: Ensures efficient movement of candy rope to the disc cutter.
• Multi-blade Disc Cutter: Executes the cutting of candy rope into discs with high precision.
• Fall Out Chute: Efficiently collects and directs the cut candy discs for further processing or packaging.

Available Models

• Logo Disc Cutter 800mm Width (DC01): Suitable for operations requiring a compact size.
• Logo Disc Cutter 1000mm Width (DC02): Ideal for larger-scale production needs.

Specifications

• Material: 304 Stainless-Steel
• Capacity: Up to 150Kg per hour depending on sweet size.
• Power: 380v 3-Phase
• DC01 – 800mm Model Dimensions:
  Dimensions: (L)1200mm x (W)900mm x (H)1500mm
  Weight: 465Kg
• DC02 – 1000mm Model Dimensions
  Dimensions: (L)1000mm x (W)900mm (H)1500mm
  Weight: 565Kg
• Products: hard candy, soft candy, caramel
